Slope Cross - 0°-11° (Interclamp Code 156)
HomeStore

Slope Cross - 0°-11° (Interclamp Code 156)

Slope Cross - 0°-11° (Interclamp Code 156)

Select Size
Select Material
From $3.65

Original: $12.17

-70%
Slope Cross - 0°-11° (Interclamp Code 156)

$12.17

$3.65

The Story

Interclamp Slope Cross - 0 to 11 Degrees (Code 156)

This fitting can be adapted for slight inclines between 0° and 11°, commonly employed between a middle rail and uprights on sloped areas, often combined with type 153 or 155.

The vertical through tube (shown in the photo) cannot be connected within the fitting; the upright must remain unbroken, with the cross rails trimmed accordingly.

Qty: 1
Finish:
 Galvanised
Brand: Interclamp®
Interclamp code: 156

Sizes:
• B34 | For 34mm Galvanised Pipe | 'a' 112mm | Weight: 0.54kg
• C42 | For 42mm Galvanised Pipe | 'a' 140mm | Weight: 0.73kg
• D48 | For 48mm Galvanised Pipe | 'a' 158mm | Weight: 0.88kg

'a' - refer to diagram

Chain.com.au is an official Interclamp® distributor. Shop rail and pipe fittings by Interclamp online now. View the range.

We are in the process of adding more Interclamp® products to our website. In the meantime, you can browse the digital catalogue and contact us to place your order.

Delivery or 'click and collect' is available from East Keilor, Melbourne (Victoria, Australia) - select option at checkout.

If you need product advice, have any questions or to bulk buy, email or call us on 03 9331 5544.

Slope Cross - 0°-11° (Interclamp Code 156) - Image 2

Details & Craftsmanship

Every detail has been carefully considered to bring you the perfect product.

Slope Cross - 0°-11° (Interclamp Code 156) - Image 3

Details & Craftsmanship

Every detail has been carefully considered to bring you the perfect product.

Description

Interclamp Slope Cross - 0 to 11 Degrees (Code 156)

This fitting can be adapted for slight inclines between 0° and 11°, commonly employed between a middle rail and uprights on sloped areas, often combined with type 153 or 155.

The vertical through tube (shown in the photo) cannot be connected within the fitting; the upright must remain unbroken, with the cross rails trimmed accordingly.

Qty: 1
Finish:
 Galvanised
Brand: Interclamp®
Interclamp code: 156

Sizes:
• B34 | For 34mm Galvanised Pipe | 'a' 112mm | Weight: 0.54kg
• C42 | For 42mm Galvanised Pipe | 'a' 140mm | Weight: 0.73kg
• D48 | For 48mm Galvanised Pipe | 'a' 158mm | Weight: 0.88kg

'a' - refer to diagram

Chain.com.au is an official Interclamp® distributor. Shop rail and pipe fittings by Interclamp online now. View the range.

We are in the process of adding more Interclamp® products to our website. In the meantime, you can browse the digital catalogue and contact us to place your order.

Delivery or 'click and collect' is available from East Keilor, Melbourne (Victoria, Australia) - select option at checkout.

If you need product advice, have any questions or to bulk buy, email or call us on 03 9331 5544.
